PCB DESIGN
(From Simple Layers to Complex Multilayer Boards)
PCB Design That Delivers — Always.
In a world where technology evolves by the minute, standout PCB design is key to staying ahead. At Techvis, our expert team delivers innovative,
efficient, and reliable PCB design services that power your ideas—on time and on point
Core Services
1. Schematic Capture
- Professional circuit design and Circuit Simulation
- BOM generation.
2. PCB Layout Design
- Single to multilayer (up to 12+ layers)
- High-density and compact routing
- Controlled impedance and differential pair routing
3. High-Speed Design
- DDR3/DDR4, USB 3.0, PCIe, Ethernet
- Signal integrity and power integrity management
4. RF & Mixed Signal Design
- RF PCB with impedance matching and shielding
- Analog-digital isolation techniques
5. DFM, DFT & DFA Compliance
- Design for Manufacturing, Testability, and Assembly
- Ready for volume production
Special Capabilities
- High speed, multi-layer PCB designs
- Impedance matched routing With delay tunning
- DDR2, DDR3, DDR4 routing and compliance
- High density SMT designs (BGA, micro BGA)
- HDI PCB Designs (Type I, Type II, Type III)
- EMI/EMC compliant routing
- Mixed Signal board design for Rx/Tx applications
- Regid-Flex PCB designs
- Extensive RF and analog design
- DFM (Design For Manufacturing)
- Blind & Buried Via Design
- Thermal Management Solutions
Tool Expertise
- Altium Designer
- Cadence Allegro / OrCAD
- CADSTAR
Industry Applications
- Automotive ECUs and EV Chargers
- Industrial Automation & Motor Controllers
- Consumer Electronics & Smart Gadgets
- Medical Monitoring Devices
- IoT, AI/ML Edge Devices
Why Choose Techvis?
- Fast Turnaround with Quality Assurance
- Cost-Effective Design
- Simulation Support
- Experienced Engineering Team with a track record of successful deployments
- Custom Design Support from Concept to Production
