We offer specialized reverse engineering services to recreate, analyze, and enhance existing electronic products and assemblies. Our team uses advanced tools and processes to deliver reliable, production-ready design data—even when original documentation is missing.

• Legacy PCB Recreation: Accurate extraction and reconstruction of schematics, Gerber files, and BOM from physical boards.
• Circuit Tracing & Netlist Generation: Manual and automated tracing to build complete netlists for design verification.
• Schematic Redrawing: Creation of clean, standardized schematics from reverse-engineered data.
• Gerber & CAM Data Regeneration: Producing precise fabrication files ready for manufacturing.
• 3D Modeling & Mechanical Reverse Engineering: Development of 3D CAD data for enclosures, mechanical parts, and connectors.
• BOM Creation & Component Identification: Identifying and documenting obsolete or unmarked parts, suggesting modern equivalents.
• Redesign & Upgrading: Improving existing designs for better performance, manufacturability, and compliance with updated standards.
• Multilayer Board Analysis: Layer-by-layer depaneling and scanning for complex multilayer boards.
• Documentation Generation: Creating complete design documentation sets including assembly drawings, fabrication notes, and test procedures.
• Design Migration: Converting legacy designs to modern CAD platforms like Altium, OrCAD, Cadence Allegro, and others.
• Obsolescence Management:Supporting life extension strategies by redesigning with available and compliant components.
• Failure Analysis & Root Cause Investigation: Studying failed boards to identify weaknesses and recommend design improvements.
